Vortex
RAZOR HD GEN III 6-36X56 FFP
Item # VORT RZR-63602PRODUCT DETAILS
TECH SPECS:
Built around the perfect balance of magnification and field of view, the Razor Gen III 6- 36x56 FFP delivers the resolution and contrast you need for long-range, tactical shooting. To get the absolute most out of the first focal plane reticle, the EBR-7D presents a clean sight picture while still providing ample wind holds and ranging information. Round it out with a rugged build and you have the long-range, tactical solution you've been waiting for.
Included in the Box
- 3 Inch Sunshade
- Throw Lever
- Lens Cloth
- CR2032 Battery
- Custom 2mm Throw Lever Tool
- 2.5mm Turret Tool
FEATURES
- First Focal Plane Reticle Scale of the EBR-7D reticle remains in proportion to the zoomed image. Constant subtensions allow for accurate holdovers and ranging at all magnifications while the EBR-7D reticle is useful for long-range shooting.
- L-Tec+™ Zero System The L-Tec+™ Zero System is easy to use with all captive parts and only one set screw, making zeroing quick and simple. Once set, it also allows for more travel.
- HD Optical System Optimized with select glass elements to deliver exceptional resolution, cut chromatic aberration and provide outstanding color fidelity, edge-to-edge sharpness and light transmission.
- Micro Adjust Zero Setting Infinite zero setting positions allow zero to be set between clicks for optimal accuracy.
- External Rotation Indicator Provides quick visual and tactile reference of elevation turret's rotational position.
- XR™ Plus Fully Multi-Coated Ultimate anti-reflective coatings on all air-to-glass surfaces provide maximum light transmission for peak clarity and the pinnacle of low-light performance.
- Optically Indexed Lenses Optimize image sharpness and brightness from edge to edge.
- Plasma Tech Cutting edge coating application process provides unparalleled coating durability and performance
- Glass-Etched Reticle Allows for intricate reticle design. Protected between two layers of glass for optimum durability and reliability.
- Aircraft-Grade Aluminum Constructed from a solid block of aircraft-grade aluminum for strength and rigidity.
- ArmorTek Ultra-hard, scratch-resistant coating protects exterior lenses from scratches, oil and dirt.
- Hard Anodized Stealth Shadow Finish Highly durable hard-coat anodization provides a low-glare matte surface and helps camouflage the shooter's position.
- Locking Side Illumination Easily accessible and lockable illumination dial is located on the left side of turret housing. Features eleven intensity levels of illumination with off positions between each setting.
- Waterproof O-ring seals prevent moisture, dust and debris from penetrating for reliable performance in all environments.
- Shockproof Rugged construction withstands recoil and impact.
- Fogproof Argon gas purging prevents internal fogging over a wide range of temperatures.
RETICLE
EBR-7D (MRAD)
Packed with useful subtension data for long-range shooting , the EBR-7D is a hashmarked, ranging reticle available in the first focal plane. A windage tree in the lower two quadrants is perfect for fast follow-up corrections for both wind and elevation. The cross-plex illumination allows for better usability at lower magnification.
Lengths | |||||
---|---|---|---|---|---|
L1 | L2 | L3 | L4 | L5 | L6 |
15.25 | 1.95 | 2.25 | 6.20 | 5.50 | 3.55 |
Heights | |
---|---|
H1 | H2 |
2.56 | 1.80 |
Magnification | 6-36x | |
Objective Lens Diameter | 56 mm | |
Eye Relief | 3.5 inches | |
Field of View | 20.5-3.5 ft @ 100 yds | |
Tube Size | 34 mm | |
Turret Style | Exposed Locking | |
Adjustment Graduation |
.1 MRAD |
|
Travel Per Rotation | 10 MRAD | |
Max Elevation Adjustment |
36.1 MRAD |
|
Max Windage Adjustment | 15.5 MRAD | |
Parallax Setting | 10 yds to infinity | |
Length | 15.3 inches | |
Weight | 45.1 oz |
